MIL-PRF-123/3F
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Molded or preformed.
Lead wire: Termination C in accordance with MIL-PRF-123.
Capacitance value: See table I.
Capacitance tolerance: See table I (F = ±1 percent; J = ±5 percent; K = ±10 percent).
Operating temperature: -55°C to +125°C.
Voltage rating: See table I (B = 50 Vdc; C = 100 Vdc; D = 200 Vdc).
Marking: In accordance with MIL-PRF-123, example 2.
TABLE I. Style CKS07 characteristics.
Part or Identifying
Capacitance
Capacitance
Voltage-temperature
Rated voltage
Number (PIN) 1/
(pF)
tolerance
limits
(volts, dc)
M123A03BPD222-C
2,200
F, J, K
BP
200
M123A03BP-272-C
2,700
F, J, K
BP
100, 200
M123A03BP-302-C
3,000
F, J, K
BP
100, 200
M123A03BP-332-C
3,300
F, J, K
BP
100, 200
M123A03BP-362-C
3,600
F, J, K
BP
100, 200
M123A03BP-392-C
3,900
F, J, K
BP
100, 200
BP
M123A03BP-432-C
4,300
F, J, K
100, 200
BP
M123A03BP-472-C
4,700
F, J, K
100, 200
BP
M123A03BPC512-C
5,100
F, J, K
100
BP
M123A03BPC562-C
5,600
F, J, K
100
BP
M123A03BPC622-C
6,200
F, J, K
100
BP
M123A03BPC682-C
6,800
F, J, K
100
BP
M123A03BPC752-C
7,500
F, J, K
100
BP
M123A03BPC822-C
8,200
F, J, K
100
BP
M123A03BPC912-C
9,100
F, J, K
100
M123A03BPC103-C
10,000
F, J, K
BP
100
M123A03BP-113-C
11,000
F, J, K
BP
50, 100
M123A03BP-123-C
12,000
F, J, K
BP
50, 100
M123A03BPB133-C
13,000
F, J, K
BP
50
M123A03BP-153-C
15,000
F, J, K
BP
50, 100
M123A03BPB163-C
16,000
F, J, K
BP
50
M123A03BP-183-C
18,000
F, J, K
BP
50, 100
BP
M123A03BPB203-C
20,000
F, J, K
50
BP
M123A03BPB223-C
22,000
F, J, K
50
BP
M123A03BPB243-C
24,000
F, J, K
50
BP
M123A03BPB273-C
27,000
F, J, K
50
BP
M123A03BPB303-C
30,000
F, J, K
50
BP
M123A03BPB333-C
33,000
F, J, K
50
BP
M123A03BPB363-C
36,000
F, J, K
50
BP
M123A03BPB393-C
39,000
F, J, K
50
BP
M123A03BPB433-C
43,000
F, J, K
50
BP
M123A03BPB473-C
47,000
F, J, K
50
M123A03BPB513-C
51,000
F, J, K
BP
50
See footnote at end of table.
