MIL-PRF-123/13E
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Multilayer, unencapsulated, monolithic ceramic.
Termination: In accordance with MIL-PRF-123.
Capacitance value: See table I.
Capacitance tolerance: See table I (F = ±1 percent; J = ±5 percent; K = ±10 percent).
Operating temperature: -55°C to +125°C.
Rated voltage: 50 V dc.
Marking: In accordance with MIL-PRF-123.
TABLE I. Style CKS54 characteristics.
Part or Identifying
Capacitance
Capacitance
Voltage-temperature
Rated voltage
Number (PIN) 1/
(pF)
tolerance
limits
(volts)
M123A13BPB112 - -
1,100
F, J, K
BP
50
M123A13BPB122 - -
1,200
F, J, K
BP
50
M123A13BPB132 - -
1,300
F, J, K
BP
50
M123A13BPB152 - -
1,500
F, J, K
BP
50
M123A13BPB162 - -
1,600
F, J, K
BP
50
M123A13BPB182 - -
1,800
F, J, K
BP
50
M123A13BPB202 - -
2,000
F, J, K
50
BP
M123A13BPB222 - -
2,200
F, J, K
50
BP
M123A13BPB242 - -
2,400
F, J, K
50
BP
M123A13BPB272 - -
2,700
F, J, K
50
BP
M123A13BPB302 - -
3,000
F, J, K
50
BP
M123A13BPB332 - -
3,300
F, J, K
50
BP
M123A13BPB362 - -
3,600
F, J, K
50
BP
M123A13BPB392 - -
3,900
F, J, K
50
BP
M123A13BPB432 - -
4,300
F, J, K
50
BP
M123A13BPB472 - -
4,700
F, J, K
50
BP
M123A13BPB512 - -
5,100
F, J, K
50
BP
M123A13BPB562 - -
5,600
F, J, K
50
BP
M123A13BPB622 - -
6,200
F, J, K
50
BP
M123A13BPB682 - -
6,800
F, J, K
50
BP
M123A13BPB752 - -
7,500
F, J, K
50
BP
M123A13BPB822 - -
8,200
F, J, K
50
BP
M123A13BPB912 - -
9,100
F, J, K
50
BP
M123A13BPB103 - -
10,000
F, J, K
BP
50
M123A13BXB124K -
120,000
K
BX
50
M123A13BXB154K -
150,000
K
BX
50
M123A13BXB184K -
180,000
K
BX
50
M123A13BXB224K -
220,000
K
BX
50
M123A13BXB274K -
270,000
K
BX
50
M123A13BXB334K -
330,000
K
BX
50
M123A13BXB394K -
390,000
K
BX
50
M123A13BXB474K -
470,000
K
BX
50
M123A13BXB105K -
1,000,000
K
BX
50
1/ The complete PIN will include additional letter(s) to indicate capacitance tolerance and termination, as applicable.
