INCH-POUND
MIL-PRF-123/13E
31 January 2014
SUPERSEDING
MIL-PRF-123/13D
31 August 2007
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, FIXED, CERAMIC DIELECTRIC,
(TEMPERATURE STABLE AND GENERAL PURPOSE),
HIGH RELIABILITY, NONLEADED, STYLE CKS54
This specification sheet is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-123.
Inches
mm
T
L
W
S
.010
0.25
±.015
±.015
±.010
Min
Max
.015
0.38
.020
0.51
.220
.250
.020
.020
.070
1.78
.070
.220
5.59
.250
6.35
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Dimensions and tolerances are for bare chips. For solder coated terminations, add .025 inch (0.64 mm) to the
positive length tolerance and .015 inch to the positive width and thickness tolerances.
FIGURE 1. Style CKS54 capacitors.
AMSC N/A
FSC 5910
