MIL-PRF-123/12D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Multilayer, unencapsulated, monolithic ceramic.
*
Termination: M, G, S, or Z in accordance with MIL-PRF-123.
Capacitance value: See table I.
*
Capacitance tolerance: See table I. (F = ±1 percent; J = ±5 percent; K = ±10 percent.)
Operating temperature: -55°C to +125°C.
*
Rated voltage: See table I. 50 Vdc (voltage code B) and 100 Vdc (voltage code C).
Marking: In accordance with MIL-PRF-123.
*
TABLE I. Style CKS53 characteristics.
Part or Identifying
Capacitance
Capacitance
Voltage-temperature
Rated voltage
Number (PIN) 1/
(pF)
tolerance
limits
(V dc)
M123A12BP-301--
300
F, J, K
BP
50, 100
M123A12BP-331--
330
F, J, K
BP
50, 100
M123A12BP-361--
360
F, J, K
BP
50, 100
M123A12BP-391--
390
F, J, K
BP
50, 100
M123A12BP-431--
430
F, J, K
BP
50, 100
M123A12BP-471--
470
F, J, K
BP
50, 100
M123A12BP-511--
510
F, J, K
BP
50, 100
M123A12BP-561--
560
F, J, K
BP
50, 100
M123A12BP-621--
620
F, J, K
BP
50, 100
M123A12BP-681--
680
F, J, K
BP
50, 100
M123A12BP-751--
750
F, J, K
BP
50, 100
M123A12BP-821--
820
F, J, K
BP
50, 100
M123A12BP-911--
910
F, J, K
BP
50, 100
M123A12BP-102--
1,000
F, J, K
BP
50, 100
50, 100
BX
K
5,600
M123A12BX-562K-
50, 100
BX
K
6,800
M123A12BX-682K-
50, 100
BX
K
8,200
M123A12BX-822K-
50, 100
BX
K
10,000
M123A12BX-103K-
50, 100
BX
K
12,000
M123A12BX-123K-
50, 100
BX
K
15,000
M123A12BX-153K-
50, 100
BX
K
18,000
M123A12BX-183K-
50, 100
BX
K
22,000
M123A12BX-223K-
50, 100
BX
K
27,000
M123A12BX-273K-
50, 100
BX
K
33,000
M123A12BX-333K-
50
BX
K
39,000
M123A12BXB393K-
50
BX
K
47,000
M123A12BXB473K-
50
BX
K
56,000
M123A12BXB563K-
50
BX
K
68,000
M123A12BXB683K-
50
BX
K
82,000
M123A12BXB823K-
50
BX
K
100,000
M123A12BXB104K-
1/ The complete PIN will include additional letter(s) to indicate voltage, capacitance tolerance, and termination,
as applicable.
2
