MIL-PRF-123/1E
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Molded or preformed.
Lead wire: Termination C in accordance with MIL-PRF-123.
Capacitance value: See table I.
Capacitance tolerance: See table I (C = ±0.25 pF; D = ±0.5 pF; F = ±1 percent; J = ±5 percent; K = ±10 percent).
Operating temperature range: -55°C to +125°C.
Voltage rating: See table I (B = 50 Vdc; C = 100 Vdc; D = 200 Vdc).
Marking: In accordance with MIL-PRF-123, example 1.
TABLE I. Style CKS05 characteristics.
Part or Identifying
Capacitance
Capacitance
Voltage-temperature
Rated voltage
Number (PIN) 1/
(pF)
tolerance
limits
(volts, dc)
M123A01BPC4R7-C
4.7
C, D
BP
100
M123A01BPC5R1-C
5.1
C, D
BP
100
M123A01BPC5R6-C
5.6
C, D
BP
100
M123A01BPC6R2-C
6.2
C, D
BP
100
M123A01BPC6R8-C
6.8
C, D
BP
100
M123A01BPC7R5-C
7.5
C, D
BP
100
M123A01BPC8R2-C
8.2
C, D
BP
100
M123A01BPC9R1-C
9.1
C, D
BP
100
M123A01BPC100-C
10
C, J, K
BP
100
M123A01BPC110-C
11
C, J, K
BP
100
M123A01BPC120-C
12
C, J, K
BP
100
M123A01BPC130-C
13
C, J, K
BP
100
M123A01BPC150-C
15
C, J, K
BP
100
M123A01BPC160-C
16
C, J, K
BP
100
M123A01BPC180-C
18
C, J, K
BP
100
M123A01BP-200-C
20
C, J, K
BP
100, 200
M123A01BP-220-C
22
C, J, K
BP
100, 200
M123A01BP-240-C
24
C, J, K
BP
100, 200
M123A01BP-270-C
27
F, J, K
BP
100, 200
M123A01BP-300-C
30
F, J, K
BP
100, 200
M123A01BP-330-C
33
F, J, K
BP
100, 200
M123A01BP-360-C
36
F, J, K
BP
100, 200
M123A01BP-390-C
39
F, J, K
BP
100, 200
M123A01BP-430-C
43
F, J, K
BP
100, 200
M123A01BP-470-C
47
F, J, K
BP
100, 200
M123A01BP-510-C
51
F, J, K
BP
100, 200
M123A01BP-560-C
56
F, J, K
BP
100, 200
M123A01BP-620-C
62
F, J, K
BP
100, 200
See footnote at end of table.
2
