MIL-PRF-11693/7F
Insertion loss: Measurements shall be made at the following frequencies for the capacitance values specified.
Nominal
Frequency
capacitance (µF)
(MHz)
0.0047
400 and 1,000
0.01
400 and 1,000
0.047
400 and 1,000
0.1
400 and 200
0.22
400 and 100
0.47
400 and 80
1.0
400 and 50
2.0
400 and 50
DC resistance: The dc resistance shall not exceed 0.01 ohm.
Vibration, high frequency: Method 204 of MIL-STD-202 condition A (10G).
Thermal shock: Method 107 of MIL-STD-202.
IR at +25°C: Not less than 30 percent of the value specified in the initial requirement.
Capacitance: Change not more than ±5 percent from the initial measurement.
Moisture resistance: Method 106 of MIL-STD-202.
IR at +25°C: Not less than 30 percent of the initial requirement.
Capacitance: Change not more than ±5 percent from the initial measurement.
Solderability: Applicable for styles CZ23, CZ24, CZR23, and CZR24.
Life (accelerated): Method 108 of MIL-STD-202.
IR at +25°C: Not less than 30 percent of the value specified in the initial requirement.
Capacitance: Change not more than ±5 percent from the initial measured value.
Changes from previous issue: The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 85
(Project 5910-2013-007)
DLA - CC
Review activities:
Army - EA, MI
Air Force 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil/.
4
