MIL-PRF-11693/7F
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.05
1.3
.312
7.92
1.12
28.5
.002
0.05
.062
1.57
.400
10.16
1.38
35.1
.005
0.13
.109
2.77
.438
11.13
1.625
41.28
.015
0.38
.125
3.18
.562
14.27
1.88
47.8
.016
0.41
.234
5.94
.670
17.02
2.12
53.9
.020
0.51
.250
6.35
.75
19.1
2.38
60.5
.031
0.79
.255
6.48
.88
22.4
2.625
66.68
.040
1.02
.281
7.14
1.00
25.4
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.031 inch (0.79 mm).
4. Threaded neck to mounting shoulder shall be perpendicular with ±3°.
5. Recommended mounting torque: 10 pound-inches.
6. Lockwasher shall not be cadmium plated.
FIGURE 1. Styles CZ23, CZ24, CZR23, and CZR24 capacitors - Continued.
