MIL-C-62/6D
TABLE I. Styles CE41 and CE44 capacitors - Continued.
Dissipation
Maximum
DC
PIN 1/
Capaci-
DC
Case
factor per
Impedance
leakage current
tance
rated
Dimension 2/
section
per section
per
voltage
A 3/
at 120 +10, -5 Hz
section
per section
±. 062 (1.57)
at -40°C +0, -3°C
μF
μA
volts
ohms
percent
inches
CE4-C100Q
400
1,480
17
1.750
10
94
(44.45)
CE4-C270Q
400
550
17
2.250
27
156
(57.15)
CE4-C330Q
400
450
17
2.250
33
172
(57.15)
CE4-C470Q
400
314
17
2.250
47
206
(57.15)
CE4-C680Q
400
218
17
2.500
68
248
(63.50)
CE4-C820Q
400
180
17
2.750
82
271
(69.85)
CE4-C101Q
400
148
17
3.250
100
300
(82.55)
CE4-C151Q
400
99
17
4.250
150
368
(107.95)
2.250
17
2,200
100
450
10
CE4-C101R
(57. 15)
2.250
17
1,465
123
450
15
CE4-C150R
(57.15)
17
815
168
450
27
CE4-C270R
2.250
(57. 15)
17
666
182
450
33
CE4-C330R
2.250
(57.15)
17
468
217
450
47
CE4-C470R
2.750
(69.85)
17
323
262
450
68
CE4-C680R
3.250
(82.55)
17
268
289
450
82
CE4-C820R
3.500
(88.90)
17
220
318
450
100
CE4-C101R
4.250
(107.95)
1/ Complete PIN shall include an additional digit to complete style.
2/ Metric equivalents are given for general information only.
3/ The dimensions shown are for style CE41; for style CE44, add .062 (1.57) ± .062 (1.57) to the nominal
dimension.
5
