MIL-C-62/1D
Application data:
All capacitors shall withstand an rms ripple
current at 120 Hz and 85C as determined
from the formula:
Ir k C
Where:
Ir = rms ripple current in milliamps.
C = nominal capacitance in microfarads.
k = 20 for units rated at 5 to 250 volts dc inclusive.
= 30 for units rated at 300 to 450 volts dc inclusive.
Supersession data: See table II.
NOTES:
Reference documents. In addition to MIL-C-62, this specification sheet references the following documents.
(Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch or https://assist.daps.dla.mil
or from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-
5094).
Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to the
previous issue due to the extent of the changes.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 85
DLA - CC
Review activities:
(Project 5910-2008-031)
Army - AT, AV, CR4, MI
Navy - AS, MC, OS
Air Force - 19, 99
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil
8
