INCH-POUND
MIL-C-25/6E
23 March 2013
SUPERSEDING
MIL-C-25/6D
12 January 2004
MILITARY SPECIFICATION SHEET
CAPACITORS, FIXED, PAPER OR PLASTIC DIELECTRIC,
DIRECT CURRENT
(HERMETICALLY SEALED IN METAL CASES),
STYLES CP67 AND CP69
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification and MIL-C-25.
INACTIVE FOR NEW DESIGN
after 21 June 1968
REQUIREMENTS:
Dimensions: See figure 1, table I, and table II.
Case: Magnetic or nonmagnetic material, uninsulated.
Design and construction: Capacitors shall be of the design, construction and physical dimensions as
specified in figure 1, table I, and table II.
Capacitance value: See table I.
Capacitance tolerance: See table I.
DC voltage rating: See table I.
Operating temperature range: -55°C to +85°C.
Terminal: Symbol B, solder lug (nonremovable).
Voltage derating with temperature: See figure 2.
Capacitance: When measured as specified in MIL-C-25, shall be within the tolerance specified in table I.
Dissipation factor: When measured as specified in MIL-C-25, shall not exceed 1 percent.
AMSC N/A
FSC 5910
