MIL-C-19978/17B

Terminal to case: Greater than 10,000 megohms.

Vibration, high frequency: Method 204 of MIL-STD-202, test condition B, with the following exception:

Direction and duration of motion - 4 hours in each of two mutually perpendicular directions (total of 8 hours), one

parallel and the other perpendicular to the cylindrical axis.

Salt spray: In accordance with MIL-PRF-19978.

Solderability: In accordance with MIL-PRF-19978.

Terminal strength: Method 211 of MIL-STD-202, test condition letter D.

Stability at low and high temperature:

Low temperature:

Test temperature: -65�C +0�, -5�C.

Capacitance change (max): -10 percent.

High temperature:

Test temperature: +125�C +5�, -0�C.

Capacitance change (max): +10 percent.

Life:

Capacitance change (max): �5 percent.

Resistance to soldering heat: In accordance with MIL-PRF-19978.

NOTE: Style CQR42 capacitors are substitutable for style CP12 capacitors formerly covered in MIL-C-25/1K as

shown in table IV.

TABLE IV. Substitutability data.

From

MIL-C-25/1K

MIL-C-19978/17

MIL-C-25/1K

MIL-C-19978/17

MIL-C-25/1K

MIL-C-19978/17

(CP12)

(CQR42)

(CP12)

(CQR42)

(CP12)

(CQR42)

CP12A-KB822K-

CQR42A-KB822K3-

CP12A-KC824K-

CQR42A-KC824K3-

CP12A-KF683K-

CQR42A-KF683K3-

CP12A-KB103K-

CQR42A-KB103K3-

CP12A-KC105K-

CQR42A-KC105K3-

CP12A-KF823K-

CQR42A-KF823K3-

CP12A-KB123K-

CQR42A-KB123K3-

CP12A-KE272K-

CQR42A-KE272K3-

CP12A-KF104K-

CQR42A-KF104K3-

CP12A-KB153K-

CQR42A-KB153K3-

CP12A-KE332K-

CQR42A-KE332K3-

CP12A-KF124K-

CQR42A-KF124K3-

CP12A-KB393K-

CQR42A-KB393K3-

CP12A-KE123K-

CQR42A-KE123K3-

CP12A-KF154K-

CQR42A-KF154K3-

CP12A-KB473K-

CQR42A-KB473K3-

CP12A-KE153K-

CQR42A-KE153K3-

CP12A-KF184K-

CQR42A-KF184K3-

CP12A-KB823K-

CQR42A-KB823K3-

CP12A-KE273K-

CQR42A-KE273K3-

CP12A-KF224K-

CQR42A-KF224K3-

CP12A-KB104K-

CQR42A-KB104K3-

CP12A-KE333K-

CQR42A-KE333K3-

CP12A-KF274K-

CQR42A-KF274K3-

CP12A-KB124K-

CQR42A-KB124K3-

CP12A-KE393K-

CQR42A-KE393K3-

CP12A-KF334K-

CQR42A-KF334K3-

CP12A-KB154K-

CQR42A-KB154K3-

CP12A-KE473K-

CQR42A-KE473K3-

CP12A-KF394K-

CQR42A-KF394K3-

CP12A-KB184K-

CQR42A-KB184K3-

CP12A-KE563K-

CQR42A-KE563K3-

CP12A-KF474K-

CQR42A-KF474K3-

CP12A-KB224K-

CQR42A-KB224K3-

CP12A-KE683K-

CQR42A-KE683K3-

CP12A-KG102K-

CQR42A-KG102K3-

CP12A-KB274K-

CQR42A-KB274K3-

CP12A-KE823K-

CQR42A-KE823K3-

CP12A-KG122K-

CQR42A-KG122K3-

CP12A-KB334K-

CQR42A-KB334K3-

CP12A-KE104K-

CQR42A-KE104K3-

CP12A-KG152K-

CQR42A-KG152K3-

CP12A-KB394K-

CQR42A-KB394K3-

CP12A-KE124K-

CQR42A-KE124K3-

CP12A-KG182K-

CQR42A-KG182K3-
