MIL-C-19978/17B
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
TABLE I. Styles CQR42 capacitors.
Capacitance
Failure
Part or
DC voltage
Case dimensions (inches) 2/
(µF)
rate level
Identifying
rating
Circuit 1
Circuit 3
Number (PIN) 1/
(volts)
L ±.031
D+.015 L ±.031
D+.015
-.005
-.005
CQR42A-KB822K3-
100
.0082
M, P, R, S
.750
.235
.688
.235
CQR42A-KB103K3-
100
.010
M, P, R, S
.750
.235
.688
.235
CQR42A-KB123K3-
100
.012
M, P, R, S
.750
.235
.688
.235
CQR42A-KB153K3-
100
.015
M, P, R, S
.750
.235
.688
.235
CQR42A-KB393K3-
100
.039
M, P, R, S
.875
.312
.812
.312
CQR42A-KB473K3-
100
.047
M, P, R, S
.875
.312
.812
.312
CQR42A-KB823K3-
100
.082
M, P, R, S
.875
.400
.812
.400
CQR42A-KB104K3-
100
.10
M, P, R, S
.875
.400
.812
.400
CQR42A-KB124K3-
100
.12
M, P, R, S
1.125
.400
1.062
.400
CQR42A-KB154K3-
100
.15
M, P, R, S
1.125
.400
1.062
.400
CQR42A-KB184K3-
100
.18
M, P, R, S
1.375
.400
1.312
.400
CQR42A-KB224K3-
100
.22
M, P, R, S
1.375
.400
1.312
.400
CQR42A-KB274K3-
100
.27
M, P, R, S
1.125
.562
1.062
.562
CQR42A-KB334K3-
100
.33
M, P, R, S
1.125
.562
1.062
.562
CQR42A-KB394K3-
100
.39
M, P, R, S
1.375
.562
1.312
.562
CQR42A-KB474K3-
100
.47
M, P, R, S
1.375
.562
1.312
.562
CQR42A-KB564K3-
100
.56
M, P, R, S
1.625
.562
1.562
.562
CQR42A-KB684K3-
100
.68
M, P, R, S
1.625
.562
1.562
.562
CQR42A-KB824K3-
100
.82
M, P, R, S
1.625
.670
1.562
.670
CQR42A-KB105K3-
100
1.0
M, P, R, S
1.625
.670
1.562
.670
CQR42A-KC392K3-
200
.0039
M, P, R, S
.750
.235
.688
.235
CQR42A-KC472K3-
200
.0047
M, P, R, S
.750
.235
.688
.235
CQR42A-KC562K3-
200
.0056
M, P, R, S
.750
.235
.688
.235
CQR42A-KC682K3-
200
.0068
M, P, R, S
.750
.235
.688
.235
CQR42A-KC183K3-
200
.018
M, P, R, S
.875
.312
.812
.312
CQR42A-KC223K3-
200
.022
M, P, R, S
.875
.312
.812
.312
CQR42A-KC273K3-
200
.027
M, P, R, S
.875
.312
.812
.312
CQR42A-KC333K3-
200
.033
M, P, R, S
.875
.312
.812
.312
CQR42A-KC393K3-
200
.039
M, P, R, S
.875
.400
.812
.400
CQR42A-KC473K3-
200
.047
M, P, R, S
.875
.400
.812
.400
CQR42A-KC563K3-
200
.056
M, P, R, S
.875
.400
.812
.400
CQR42A-KC683K3-
200
.068
M, P, R, S
.875
.400
.812
.400
CQR42A-KC823K3-
200
.082
M, P, R, S
1.125
.400
1.062
.400
CQR42A-KC104K3-
200
.10
M, P, R, S
1.125
.400
1.062
.400
CQR42A-KC124K3-
200
.12
M, P, R, S
1.375
.400
1.312
.400
CQR42A-KC154K3-
200
.15
M, P, R, S
1.375
.400
1.312
.400
CQR42A-KC184K3-
200
.18
M, P, R, S
1.125
.562
1.062
.562
CQR42A-KC224K3-
200
.22
M, P, R, S
1.125
.562
1.062
.562
CQR42A-KC274K3-
200
.27
M, P, R, S
1.375
.562
1.312
.562
CQR42A-KC334K3-
200
.33
M, P, R, S
1.375
.562
1.312
.562
CQR42A-KC394K3-
200
.39
M, P, R, S
1.625
.562
1.562
.562
CQR42A-KC474K3-
200
.47
M, P, R, S
1.625
.562
1.562
.562
CQR42A-KC564K3-
200
.56
M, P, R, S
1.625
.670
1.562
.670
CQR42A-KC684K3-
200
.68
M, P, R, S
1.625
.670
1.562
.670
See footnotes at end of table.
