MIL-C-18312/3D
REQUIREMENTS:
Dimensions: See figure 1 and table I.
TABLE I. Characteristics.
Superseded
Dimensions, nominal (inches)
DC
dash numbers
Capacitance
Part or Identifying
rated
Circuit
Capacitance
value
Number (PIN)
voltage
diagram
(µF)
tolerance
(volts)
L
D
H
G
E
F
±10%
±20%
±.062
±.031
±.062
±.062
±.031
±.005
CH12A1NC104-
200
0.10
1
.844
.312
.312
.250
.188
.144
0201
0202
CH12A3NC104-
200
0.10
3
.781
.312
.312
.250
.188
.144
0203
0204
CH12A1NC224-
200
0.22
1
1.125
.312
.312
.250
.188
.144
0205
0206
CH12A3NC224-
200
0.22
3
1.062
.312
.312
.250
.188
.144
0207
0208
CH12A1NC474-
200
0.47
1
1.125
.400
.312
.250
.188
.144
0209
0210
CH12A3NC474-
200
0.47
3
1.062
.400
.312
.250
.188
.144
0211
0212
CH12A1NC105-
200
1.0
1
1.125
.562
.438
.500
.250
.156
0213
0214
CH12A3NC105-
200
1.0
3
1.062
.562
.438
.500
.250
.156
0215
0216
CH12A1NC155-
200
1.5
1
1.844
.562
.438
.500
.250
.156
0217
0218
CH12A3NC155-
200
1.5
3
1.781
.562
.438
.500
.250
.156
0219
0220
CH12A1NC225-
200
2.2
1
1.844
.562
.438
.500
.250
.156
0221
0222
CH12A3NC225-
200
2.2
3
1.781
.562
.438
.500
.250
.156
0223
0224
CH12A1NC335-
200
3.3
1
1.875
.670
.438
.500
.250
.156
0225
0226
CH12A3NC335-
200
3.3
3
1.812
.670
.438
.500
.250
.156
0227
0228
CH12A1NC475-
200
4.7
1
1.875
1.000
.438
.500
.250
.156
0229
0230
CH12A3NC475-
200
4.7
3
1.812
1.000
.438
.500
.250
.156
0231
0232
CH12A1NC685-
200
6.8
1
1.875
1.000
.438
.500
.250
.156
0233
0234
CH12A3NC685-
200
6.8
3
1.812
1.000
.438
.500
.250
.156
0235
0236
CH12A1NC106-
200
10.0
1
2.375
1.000
.438
.500
.250
.156
0237
0238
CH12A3NC106-
200
10.0
3
2.312
1.000
.438
.500
.250
.156
0239
0240
CH12A1NC126-
200
12.0
1
2.625
1.000
.438
.500
.250
.156
0241
0242
CH12A3NC126-
200
12.0
3
2.562
1.000
.438
.500
.250
.156
0243
0244
CH12A1NE473-
400
0.047
1
1.125
.312
.312
.250
.188
.144
0245
0246
CH12A3NE473-
400
0.047
3
1.062
.312
.312
.250
.188
.144
0247
0248
CH12A1NE104-
400
0.10
1
1.125
.400
.312
.250
.188
.144
0249
0250
CH12A3NE104-
400
0.10
3
1.062
.400
.312
.250
.188
.144
0251
0252
CH12A1NE224-
400
0.22
1
1.125
.562
.438
.500
.250
.156
0253
0254
CH12A3NE224-
400
0.22
3
1.062
.562
.438
.500
.250
.156
0255
0256
CH12A1NE474-
400
0.47
1
1.625
.562
.438
.500
.250
.156
0257
0258
CH12A3NE474-
400
0.47
3
1.562
.562
.438
.500
.250
.156
0259
0260
CH12A1NE105-
400
1.0
1
1.875
.750
.438
.500
.250
.156
0261
0262
CH12A3NE105-
400
1.0
3
1.812
.750
.438
.500
.250
.156
0263
0264
CH12A1NE225-
400
2.2
1
2.125
1.000
.438
.500
.250
.156
0265
0266
CH12A3NE225-
400
2.2
3
2.062
1.000
.438
.500
.250
.156
0267
0268
CH12A1NE335-
400
3.3
1
2.625
1.000
.438
.500
.250
.156
0269
0270
CH12A3NE335-
400
3.3
3
2.562
1.000
.438
.500
.250
.156
0271
0272
CH12A1NF103-
600
0.01
1
.812
.312
.312
.250
.188
.144
0273
0274
CH12A3NF103-
600
0.01
3
.750
.312
.312
.250
.188
.144
0275
0276
CH12A1NF223-
600
0.022
1
.812
.312
.312
.250
.188
.144
0277
0278
CH12A3NF223-
600
0.022
3
.750
.312
.312
.250
.188
.144
0279
0280
CH12A1NF473-
600
0.047
1
1.125
.400
.312
.250
.188
.144
0281
0282
CH12A3NF473-
600
0.047
3
1.062
.400
.312
.250
.188
.144
0283
0284
