MIL-C-11272/3C
Qualification inspection: Capacitors shall meet the following requirements, as applicable:
For qualification test:
At 25°C:
Insulation resistance: 100,000 megohms minimum.
Capacitance: Change not more than 0.5 percent of nominal value or 0.5 pF whichever is greater, from
initial 125°C value.
Dissipation factor: Not to exceed 0.0025.
At 125°C:
Insulation resistance: Not less than 10,000 megohms.
Capacitance: Change not more than 0.5 percent of nominal value or 0.5 pF whichever is greater, from
initial 125°C value.
Dissipation factor: Not to exceed 0.007.
Performance check: Capacitors shall meet the following requirements:
For performance check:
Insulation resistance: 100,000 megohms minimum.
Capacitance: Change not more than 0.5 percent of nominal value or 0.5 pF whichever is greater, from
initial 125°C value.
Dissipation factor: Not to exceed 0.0025.
Temperature coefficient and capacitance drift: The temperature coefficient and capacitance drift shall be within
the limits specified in table II.
TABLE II. Temperature coefficient and capacitance drift.
Temperature
Capacitance drift
(-55° to +125°C)
coefficient
parts/million/°C
0.1 percent or 0.1 pF,
140 ±25
whichever is greater.
VERIFICATION:
Sampling and inspection shall be in accordance with MIL-C-11272.
Group A inspection: See MIL-C-11272: Successful performance of group A inspection.
Group B inspection: See MIL-C-11272: Successful performance of group B inspection.
3
