MIL-C-11272/3C
REQUIREMENTS:
Requirements: Requirements shall be in accordance with MIL-C-11272, and as specified herein.
Design and construction: Capacitors shall be of the design, construction, and physical dimensions specified on
figure 1 and in table I.
TABLE I. Style CY20.
Pin 1/
DC
Capacitance
Capacitance
rated
tolerances
voltage
available
pF
volts
CY20C561-
560
500
FGJ
CY20C621-
620
500
FGJ
CY20C681-
680
500
FGJ
CY20C751-
750
500
FGJ
CY20C821-
820
500
FGJ
CY20C911-
910
500
FGJ
CY20C102-
1,000
500
FGJ
CY20C112-
1,100
500
FGJ
CY20C122-
1,200
500
FGJ
CY20C132-
1,300
500
FGJ
CY20C152-
1,500
500
FGJ
CY20C162-
1,600
500
FGJ
CY20C182-
1,800
500
FGJ
CY20C202-
2,000
500
FGJ
CY20C222-
2,200
500
FGJ
CY20C242-
2,400
500
FGJ
CY20C272-
2,700
500
FGJ
CY20C302-
3,000
500
FGJ
CY20C332-
3,300
500
FGJ
CY20C362-
3,600
300
FGJ
CY20C392-
3,900
300
FGJ
CY20C432-
4,300
300
FGJ
CY20C472-
4,700
300
FGJ
CY20C512-
5,100
300
FGJ
1/ Complete type designation will include an additional letter
symbol to indicate capacitance tolerance, where applicable.
Capacitance: See table I.
Capacitance tolerance: C: ± 0.25 pF, D: ± 0.50 pF, F: 1%, G: 2%, J: 5%.
DC rated voltage: 300 and 500 volts.
Temperature range: -55°C to +125°C.
Life: 150 percent dc rated voltage at 125°C +4°C, -0°C for 2,000 hours.
Group A test: 250 hours: group B continuation test for 1,750 hours.
2
