MIL-C-11272/16B
TABLE 1. Styles CY81 and CY82 - Continued.
Capacitance
Tolerance
PIN 1/
Capacitance
Rated
available
Voltage
CY8-D300-
30
50
F, G, J, K, M
CY8-D330-
33
50
F, G, J, K, M
CY8-D360-
36
50
F, G, J, K, M
CY8-D390-
39
50
F, G, J, K, M
CY8-D430-
43
50
F, G, J, K, M
CY8-D470-
47
50
F, G, J, K, M
CY8-D510-
51
50
F, G, J, K, M
CY8-D560-
56
50
F, G, J, K, M
CY8-D620-
62
50
F, G, J, K, M
CY8-D680-
68
50
F, G, J, K, M
CY8-D750-
75
50
F, G, J, K, M
CY8-D820-
82
50
F, G, J, K, M
CY8-D910-
91
50
F, G, J, K, M
CY8-D101-
100
50
F, G, J, K, M
1/ Complete PIN will include an additional digit to indicate the style,
and an additional letter symbol to indicate the capacitance tolerance, where
applicable.
REQUIREMENTS:
Requirements: Requirements shall be in accordance with MIL-C-11272, and as specified herein.
Design and construction: Capacitors shall be of the design, construction, and physical dimensions specified on
figure 1 and in table I.
Case type: Multi-layer, unencapsulated, monolithic.
Material: Porcelain.
Terminations:
Style CY81: Metallized.
Style CY82: Solder coated, 372°F, 62 Sn, 36P6, 2 percent Ag.
Inspection conditions: All visual examinations shall be performed using a stereo microscope having
a minimum magnification of 20 power.
Capacitance (Cap.) value: See table I.
Capacitance tolerance - F: 1%, G: 2%, J: 5%, K: 10%, M: 20%.
DC rated voltage: 50 volts.
Insulation resistance (IR):
6
At +25°C: 10 megohms, minimum.
5
At +125°C: 10 megohms, minimum.
Quality factor: 10,000. 1 MHz -0 +100 kHz.
