INCH-POUND
MIL-C-11272/16B
7 February 2003
SUPERSEDING
MIL-C-11272/16A(USAF)
6 July 1973
MILITARY SPECIFICATION
CAPACITORS, FIXED, PORCELAIN DIELECTRIC,
STYLES CY81 AND CY82
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
INACTIVE FOR DESIGN AFTER
16 JULY 1979. USE MIL-PRF-55681/4.
Inches
mm
.005
.13
.010
.25
.020
.51
.030
.76
.055
1.40
Dimensions
T
Style
L
W
Min.
Max.
.055 ±.010
.055 ±.010
CY81
.030
.055
.055 ±.020
.055 ±.010
CY82
.030
.055
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 1. Capacitors, fixed, glass dielectric,
styles CY81 and CY82.
AMSC N/A
1 of 4
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
