MIL-C-11272/15C
At 125°C:
Insulation resistance: Not less than 10,000 megohms.
Capacitance: Change not more than 0.5 percent of nominal value from initial 125°C value.
Dissipation factor: Not to exceed 0.007.
For performance check:
Insulation resistance: Not less than 100,000 megohms.
Capacitance: Change not more than 0.5 percent of nominal from initial 25°C value.
Dissipation factor: Not to exceed 0.0025.
Temperature coefficient and capacitance drift: The temperature coefficient and capacitance drift shall be
within the limits specified in table II.
TABLE II. Temperature coefficient and capacitance drift.
Temperature
Capacitance drift
(-55° to +125°C)
coefficient
parts/million/°C
0.1 percent or 0.1 pF,
140 ±25
whichever is greater.
Referenced documents. In addition to MIL-C-11272, this document also references the following:
*
*
Changes from previous issue. The margins of this specification sheet are marked with asterisks to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government
assumes no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal notations and
relationship to the last previous issue.
Custodian:
Preparing activity:
Navy - EC
DLA - CC
Air Force - 11
DLA - CC
(Project 5910-2008-007)
Review activity:
Air Force - 19, 99
*
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using
ASSIST Online database at https://assist.daps.dla.mil.
