MIL-C-11272/15C
REQUIREMENTS:
Requirements: Requirements shall be in accordance with MIL-C-11272, and as specified herein.
*
Dimensions and configuration: See Figure 1.
Material:
Dielectric: Glass.
Case: Epoxy.
*
Terminals: Solderable
Capacitance value: See table I.
Capacitance tolerance: F = ±1%; G = ±2%; J = ±5%.
DC rated voltage: 300 volts.
Dissipation factor: Not to exceed 0.001.
*
Quality factor (Q): In accordance with MIL-C-11272 and the following:
Not less than 1,000.
*
TABLE I. Style CY08.
DC rated
Capacitance
PIN 1/
Capacitance
voltage
tolerances
(pF)
available
CY08C112-
1100
300
FGJ
CY08C122-
1200
300
FGJ
CY08C132-
1300
300
FGJ
CY08C152-
1500
300
FGJ
CY08C162-
1600
300
FGJ
CY08C182-
1800
300
FGJ
CY08C202-
2000
300
FGJ
CY08C222-
2200
300
FGJ
CY08C242-
2400
300
FGJ
1/ Complete PIN will include an additional letter symbol to indicate
capacitance tolerance.
*
Life: In accordance with MIL-C-11272 and the following:
For qualification test:
At 25°C:
Insulation resistance: Not less than 100,000 megohms.
Capacitance: Change not more than 0.5 percent of nominal value from initial 25°C value.
Dissipation factor: Not to exceed 0.0025.
2
