MIL-C-11015/4D
TABLE I. Style CK27 characteristics.
Capacitance
Capacitance
PIN
1/
Rated
Rated temperature
tolerance
voltage
and voltage-
temperature limits
Volts, dc
pF
CK27AX821K
500
AX
820
K
CK27AX102-
500
AX
1,000
K, M
CK27AX122K
500
AX
1,200
K
CK27AX152-
500
AX
1,500
K, M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance.
Voltage-temperature limits: In accordance with MIL-C-11015.
Life (at elevated ambient temperature): In accordance with MIL-C-11015.
Test potential - 200 percent of rated voltage.
IR - 500 megohms, minimum (at 85 C); 10,000 megohms, minimum (at 25 C).
DF - 3 percent, maximum (at 25 C).
Marking: In accordance with MIL-C-11015.
Changes from previous issue: Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extent of the changes.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
DLA - CC
(Project 5910-2069-02)
