MIL-C-11015/32B
Salt spray (corrosion): In accordance with MIL-C-11015 and method 101 of MIL-STD-202, condition A.
Terminal strength: Not applicable.
Moisture resistance: In accordance with MIL-C-11015.
IR - 50 megohms, minimum.
Cap. - Within 10 percent of initial measurement.
Solderability: In accordance with MIL-C-11015; 2 terminals.
Resistance to soldering heat: In accordance with MIL-C-11015.
Voltage-temperature limits: In accordance with MIL-C-11015 (symbol BW).
Life (at elevated ambient temperature): In accordance with MIL-C-11015.
Test potential: 200 percent of rated voltage.
IR: 100 megohms, minimum (at 85 C);
250 megohms, minimum (at 25 C).
DF: 8.0 percent maximum (at 25 C).
Marking: Capacitors shall be marked as shown on figure 1. See table 1 for color code. The PIN, capacitance,
voltage, and the manufacturer's code or symbol shall be marked on the package container.
Supersession data: For new design, units from Military Specification, MIL-PRF-28861/12 should be used as
specified in table II.
TABLE II.
Inactive PIN
Superseding Specification Sheet
Superseding PIN
CK99BW101M
MIL-PRF-28861/12
M28861/12-012GB
CK99BW501M
MIL-PRF-28861/12
M28861/12-014GB
CK99BW122M
MIL-PRF-28861/12
M28861/12-016GB 1/
CK99BW272M
MIL-PRF-28861/12
M28861/12-004GB
CK99BW502M
MIL-PRF-28861/12
M28861/12-006GB
1/ PIN CK99BW122M has a capacitance of 1,200 pF. PIN M28861/12-016GB has a
capacitance of 1,000 pF.
Changes from previous issue: Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extent of the changes.
Custodians:
Preparing activity:
Air Force - 11
DLA - CC
Navy - EC
DLA - CC
(Project 5910-2069-14)
3
