MIL-C-11015/32B
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Feed-through (solder mount). Solder used internally shall have a minimum melting point
of 280 C.
Capacitance value - See table I.
Capacitance tolerance -
20 percent (M).
Rated temperature - -55 C to +125 C.
Rated voltage: See table I.
TABLE I. Style CK99 characteristics.
PIN
Capacitance
Rated
Color
value
voltage
dot
pF
volts, dc
CK99BW101M
100
200
Green
CK99BW501M
500
200
Brown
CK99BW122M
1,200
200
White
CK99BW272M
2,700
100
Red
CK99BW502M
5,000
50
Yellow
Dielectric withstanding voltage (DWV): In accordance with MIL-C-11015.
Dielectric:
Test voltage - 200 percent of dc rated voltage applied between the terminal and the mounting flange..
Body insulation: Not applicable.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202, condition C
(70,000 feet).
Test potential - 200 percent of dc rated voltage applied between the terminal and the mounting flange.
Insulation resistance (IR): In accordance with MIL-C-11015 and method 302 of MIL-STD-202, condition B, or
rated voltage, whichever is less, 500 megohms, minimum, measured between the terminal and the mounting
flange.
Dissipation factor (DF): 5.0 percent, maximum.
Shock (specified pulse): In accordance with MIL-C-11015 and method 213 of MIL-STD-202, condition A (50 g's).
Vibration, high frequency: In accordance with MIL-C-11015 and method 204 of MIL-STD-202, condition D (20 g's).
Mounting: Capacitors shall be rigidly mounted by the body.
Thermal shock and immersion: In accordance with MIL-C-11015.
IR: 50 megohms, minimum.
2
