MIL-C-11015/29E
Styles CK74 and CK78
Inches
mm
.048
1.22
.125
3.18
STYLE
X
Y
Z
.145
3.68
CK74
.395
.227
.250
.195
4.95
CK75
.380
.227
---
.227
5.77
CK78
.250
.195
.125
.250
6.35
CK79
.250
.195
---
.380
9.65
.395
10.03
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.015 (.38 mm).
4. Color dots indicating capacitance value read clockwise starting with 10 o'clock dot.
Dots to be located at approximately 10, 12, and 3 o'clock.
FIGURE 1. Dimensions and configuration - Continued.
2
