MIL-C-11015/23D
Solderability: In accordance with MIL-C-11015; 2 terminals.
Life (at elevated ambient temperature): In accordance with MIL-C-11015.
Test potential - 200 percent of rated voltage.
IR - 200,000 megohms, minimum (at 85 C), 300,000 megohms, minimum (at 25 C).
DF - 1.5 percent, maximum (at 25 C).
Marking: The operating temperature range and voltage-temperature limit, capacitance, and capacitance
tolerance shall be indicated on the capacitor by color coding as shown on figure 2 and table II. The MIL identifier
(yellow spot) shall be applied to the capacitor body diametrically opposite the color spots. At the option of the
manufacturer, capacitors may be marked in accordance with MIL-C-11015. In either case, full marking shall
appear on the unit package.
TABLE II. Color code.
Operating
temperature range
and voltage-
Nominal capacitance
Capacitance
Color
temperature limits
tolerance
First and second
Multiplier 1/
significant figures
Black
---
0
1
M
Brown
---
1
10
---
Red
AX
2
100
---
Orange
---
3
1000
---
Yellow
---
4
---
---
Green
---
5
---
---
Blue
---
6
---
---
Purple (violet)
---
7
---
---
Gray
---
8
---
---
White
---
9
---
---
1/ The multiplier is the factor by which the two significant figures are multiplied to yield the nominal capacitance.
3
