MIL-C-11015/23D
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Feed-thru.
Capacitance value - See table I.
Capacitance tolerance -
20 percent (M).
Rated temperature - -55 C to +85 C.
Dielectric withstanding voltage: In accordance with MIL-C-11015.
Dielectric (DWV):
Test voltage - 250 percent of rated voltage, applied between the case and the terminal.
Body insulation: Not applicable.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202, condition B
(50,000 ft).
Test potential - 1,550 volts dc.
Insulation resistance (IR): In accordance with MIL-C-11015 and method 302 of MIL-STD-202, condition B.
500,000 megohms, minimum, measured between either insulated point and capacitor case.
Dissipation factor (DF): 1.2 percent, maximum.
TABLE I. Style CK72 characteristics.
Rated
Rated temperature
Capacitance
PIN
voltage
and voltage-
Capacitance
tolerance
temperature limits
Volts, dc
pF
CK72AX101M
1,500
AX
100
M
CK72AX471M
1,500
AX
470
M
CK72AX681M
1,500
AX
680
M
CK72AX102M
1,500
AX
1,000
M
Vibration, high frequency: In accordance with MIL-C-11015 and method 204 of MIL-STD-202, condition D
(20 g's).
Thermal shock and immersion: In accordance with MIL-C-11015.
IR - 200,000 megohms, minimum.
Terminal strength: Not applicable.
Moisture resistance: In accordance with MIL-C-11015.
DWV - 250 percent of rated voltage.
IR - 150,000 megohms, minimum.
Cap. - Within tolerance of table I value.
