MIL-C-11015/21F
TABLE I. Styles CK64, CK65, CK66, CK67, CK68, and CK69 characteristics.
Capacitance
Capacitance
PIN
1/
Rated
Rated temperature
tolerance
voltage
and voltage-
temperature limits
Volts, dc
pF
CK64AW511M-
1,600
AW
510
M
CK64AW681M-
1,600
AW
680
M
CK64AW821M-
1,600
AW
820
M
CK64AW102M-
1,600
AW
1,000
M
CK64AW152M-
1,600
AW
1,500
M
CK64AW222M-
1,600
AW
2,200
M
CK64AW332M-
1,600
AW
3,300
M
CK64AW392M-
1,600
AW
3,900
M
CK65AW472M-
1,600
AW
4,700
M
CK66AW562M-
1,600
AW
5,600
M
CK67AW682M-
1,600
AW
6,800
M
CK67AW752M-
1,600
AW
7,500
M
CK68AW103M-
1,600
AW
10,000
M
CK69AW153M-
1,600
AW
15,000
M
1/ The complete PIN will include the letter "E" to indicate an epoxy coated capacitor (when applicable) or "-" will be
deleted for wax impregnated case.
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Disk, wax impregnated or epoxy coated (E).
Capacitance value - See table I.
Capacitance tolerance -
20 percent (M).
Rated temperature - -55 C to +85 C.
Dielectric withstanding voltage(DWV): In accordance with MIL-C-11015.
Dielectric:
Test voltage - 250 percent of rated voltage.
Body insulation:
Test potential 3000 volts dc.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202, condition B
(50,000 ft).
Test potential - 2,000 volts dc.
Insulation resistance (IR): In accordance with MIL-C-11015 and method 302 of MIL-STD-202, condition B.
200,000 megohms, minimum.
2
