MIL-C-11015/11F
TABLE I. Style CK62 characteristics.
Capacitance
Capacitance
Rated
Rated temperature
tolerance
voltage
and voltage
PIN
1/
temperature limits
Volts, dc
pF
CK62AY220M-
1,500
AY
22
M
CK62AY470M-
1,500
AY
47
M
CK62AY101M-
1,500
AY
100
M
CK62AY221M-
1,500
AY
220
M
CK62AY471M-
1,500
AY
470
M
CK62BX821K-
500
BX
820
K
CK62BX102--
500
BX
1,000
K, M
CK62BX152--
500
BX
1,500
K, M
CK62AX222--
500
AX
2,200
K, M
CK62AW332M-
500
AW
3,300
M
CK62AW472M-
500
AW
4,700
M
CK62AW682M-
500
AW
6,800
M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance. The PIN
will also include the letter "E" to indicate an epoxy coated capacitor (when applicable) or "-" will be deleted for wax
impregnated case.
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Disk, wax impregnated or epoxy coated (E).
Capacitance value - See table I.
Capacitance tolerance -
10 percent (K) or 20 percent (M) as shown in table I.
Rated temperature - -55 C to +85 C (A) or -55 to +125 C (B) as shown in table I.
Dielectric withstanding voltage (DWV): In accordance with MIL-C-11015.
Dielectric:
Test voltage - 250 percent of rated voltage for voltage-temperature limits W and X, or 200 percent of rated
voltage for voltage-temperature limit Y.
Body insulation:
Test potential - 1,300 volts dc.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202; condition B
(50,000 ft) for voltage-temperature limit AY, or 0.82 inch of mercury (80,000 ft) for voltage-temperature limits AW
and BX.
Test potential - 150 percent of rated voltage or 1,550 volts dc, whichever is less.
Insulation resistance (IR): In accordance with MIL-C-11015 and method 302 of MIL-STD-202, condition B.
200,000 megohms, minimum.
