INCH-POUND
MIL-PRF-87164/3A
24 May 1999
SUPERSEDING
MIL-C-87164/3
22 November 1982
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, FIXED, MICA DIELECTRIC, HIGH RELIABILITY,
STYLE CMS06
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification and MIL-PRF-87164.
Capacitance (pF)
L
T
W
Min 1/
Max
Min 1/
Max
Max
.510 (12.95)
.210 (5.33)
.090 (2.29)
.650 (16.51)
.550 (13.97)
270 to 330 inclusive
.510 (12.95)
.210 (5.33)
.090 (2.29)
.650 (16.51)
.550 (13.97)
360 and 390
.510 (12.95)
.220 (5.59)
.090 (2.29)
.650 (16.51)
.560 (14.22)
430 and 470
.520 (13.21)
.230 (5.84)
.100 (2.54)
.650 (16.51)
.560 (14.22)
510 to 620 inclusive
.530 (13.46)
.240 (6.10)
.100 (2.54)
.660 (16.78)
.560 (14.22)
680 to 910 inclusive
.530 (13.46)
.250 (6.35)
.110 (2.79)
.670 (17.02)
.560 (14.22)
1,000 and 1,100
.530 (13.46)
.260 (6.60)
.110 (2.79)
.670 (17.02)
.570 (14.48)
1,200 and 1,300
.540 (13.72)
.280 (7.11)
.120 (3.05)
.680 (17.27)
.570 (14.48)
1,500
.550 (13.97)
.290 (7.37)
.120 (3.05)
.680 (17.27)
.570 (14.48)
1,600
.560 (14.22)
.310 (7.87)
.130 (3.30)
.680 (17.27)
.580 (14.73)
1,800 to 2,000
.560 (14.22)
.330 (8.38)
.130 (3.30)
.690 (17.53)
.580 (14.73)
2,200
.570 (14.48)
.340 (8.64)
.140 (3.56)
.690 (17.53)
.580 (14.73)
2,400
.580 (14.73)
.350 (8.89)
.150 (3.81)
.700 (17.78)
.590 (14.99)
2,700
1/ Minimum dimensions are listed for information only.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are in parentheses.
3. This dimension may not be solderable as it may be covered by a clear epoxy coating.
FIGURE 1. Style CMS06.
AMSC N/A
1 of 3
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
