INCH-POUND
MIL-PRF-87164/2A
24 May 1999
SUPERSEDING
MIL-C-87164/2
22 November 1982
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, FIXED, MICA DIELECTRIC, HIGH RELIABILITY,
STYLE CMS05
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification and MIL-PRF-87164.
Capacitance (pF)
L
T
W
Min 1/
Max
Min 1/
Max
Max
.360 (9.14)
.180 (4.57)
.090 (2.29)
.460 (11.68)
.400 (10.16)
1 to 62 inclusive
.370 (9.40)
.180 (4.57)
.090 (2.29)
.460 (11.68)
.400 (10.16)
68 to 82 inclusive
.370 (9.40)
.190 (4.83)
.095 (2.41)
.460 (11.68)
.400 (10.16)
91 and 100
.380 (9.65)
.200 (5.08)
.095 (2.41)
.460 (11.68)
.400 (10.16)
110 to 130 inclusive
.390 (9.91)
.210 (5.33)
.095 (2.41)
.470 (11.94)
.400 (10.16)
150 to 180 inclusive
.390 (9.91)
.210 (5.33)
.110 (2.79)
.470 (11.94)
.400 (10.16)
200
.400 (10.16)
.220 (5.59)
.110 (2.79)
.470 (11.94)
.400 (10.16)
220 and 240
1/ Minimum dimensions are listed for information only.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are in parentheses.
3. This dimension may not be solderable as it may be covered by a clear epoxy coating.
FIGURE 1. Style CMS05.
AMSC N/A
1 of 3
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
