MIL-PRF-55514/10E
TABLE I. Capacitor characteristics.
Characteristic K, style CFR15 capacitors
Voltage
dv/dt
Capacitance dc Voltage
at +85°C
Capacitance
Part or identifying
L ± .062
volt/µs
at +105°C
D
tolerance
(µF)
number (PIN) 1/
at 20 kHz
available
(volts)
(volts)
(volts)
.179 (4.55) ± .047 (1.19)
CFR15AKC123--
.012
J, K, M
200
60
300
.750 (19.05)
.197 (5.00) ± .047 (1.19)
CFR15AKC153--
.015
J, K, M
200
60
300
.750 (19.05)
.212 (5.39) ± .047 (1.19)
CFR15AKC183--
.018
J, K, M
200
60
300
.750 (19.05)
.232 (5.89) ± .047 (1.19)
CFR15AKC223--
.022
J, K, M
200
60
300
.750 (19.05)
.251 (6.38) ± .062 (1.57)
CFR15AKC273--
.027
J, K, M
200
60
300
.750 (19.05)
.263 (6.68) ± .062 (1.57)
CFR15AKC333--
.033
J, K, M
200
60
300
.750 (19.05)
.242 (6.15) ± .062 (1.57)
CFR15AKC393--
.039
J, K, M
200
60
300
.938 (23.83)
.261 (6.63) ± .062 (1.57)
CFR15AKC473--
.047
J, K, M
200
60
300
.938 (23.83)
.270 (6.86) ± .062 (1.57)
CFR15AKC563--
.056
J, K, M
200
60
300
.938 (23.83)
.297 (7.54) ± .062 (1.57)
CFR15AKC683--
.068
J, K, M
200
60
300
.938 (23.83)
.259 (6.58) ± .062 (1.57)
CFR15AKC823--
.082
J, K, M
200
40
300
1.250 (31.75)
.284 (7.21) ± .062 (1.57)
CFR15AKC104--
.10
J, K, M
200
40
300
1.250 (31.75)
.310 (7.87) ± .062 (1.57)
CFR15AKC124--
.12
J, K, M
200
40
300
1.250 (31.75)
.345 (8.76) ± .062 (1.57)
CFR15AKC154--
.15
J, K, M
200
40
300
1.250 (31.75)
.377 (9.58) ± .062 (1.57)
CFR15AKC184--
.18
J, K, M
200
40
300
1.250 (31.75)
.416 (10.57) ± .062 (1.57)
CFR15AKC224--
.22
J, K, M
200
40
300
1.250 (31.75)
.389 (9.88) ± .062 (1.57)
CFR15AKC274--
.27
J, K, M
200
40
300
1.688 (42.88)
.427 (10.85) ± .062 (1.57)
CFR15AKC334--
.33
J, K, M
200
40
300
1.688 (42.88)
.462 (11.74) ± .062 (1.57)
CFR15AKC394--
.39
J, K, M
200
40
300
1.688 (42.88)
.501 (12.73) ± .093 (2.36)
CFR15AKC474--
.47
J, K, M
200
40
300
1.688 (42.88)
.635 (16.13) ± .093 (2.36)
CFR15AKC564--
.56
J, K, M
200
40
300
1.688 (42.88)
.706 (17.93) ± .093 (2.36)
CFR15AKC684--
.68
J, K, M
200
40
300
1.688 (42.88)
.675 (17.15) ± .093 (2.36)
CFR15AKC324--
.82
J, K, M
200
40
300
2.063 (52.40)
.748 (19.00) ± .093 (2.36)
CFR15AKC105--
1.00
J, K, M
200
40
300
2.063 (52.40)
.217 (5.51) ± .047 (1.19)
CFR15AKE682--
.0068
J, K, M
400
95
400
.750 (19.05)
.230 (5.84) ± .047 (1.19)
CFR15AKE822--
.0082
J, K, M
400
95
400
.750 (19.05)
.232 (5.89) ± .047 (1.19)
CFR15AKE103--
.01
J, K, M
400
95
400
.750 (19.05)
.250 (6.35) ± .047 (1.19)
CFR15AKE123--
.012
J, K, M
400
95
400
.750 (19.05)
.260 (6.60) ± .062 (1.57)
CFR15AKE153--
.015
J, K, M
400
95
400
.750 (19.05)
.243 (6.17) ± .047 (1.19)
CFR15AKE183--
.018
J, K, M
400
95
400
.938 (23.83)
.262 (6.66) ± .062 (1.57)
CFR15AKE223--
.022
J, K, M
400
95
400
.938 (23.83)
.275 (6.98) ± .062 (1.57)
CFR15AKE273--
.027
J, K, M
400
95
400
.938 (23.83)
.301 (7.65) ± .062 (1.57)
CFR15AKE333--
.033
J, K, M
400
95
400
.938 (23.83)
.261 (6.63) ± .062 (1.57)
CFR15AKE393--
.039
J, K, M
400
50
400
1.250 (31.75)
.284 (7.21) ± .062 (1.57)
CFR15AKE473--
.047
J, K, M
400
50
400
1.250 (31.75)
.307 (7.80) ± .062 (1.57)
CFR15AKE563--
.056
J, K, M
400
50
400
1.250 (31.75)
.336 (8.53) ± .062 (1.57)
CFR15AKE683--
.068
J, K, M
400
50
400
1.250 (31.75)
.367 (9.32) ± .062 (1.57)
CFR15AKE823--
.082
J, K, M
400
50
400
1.250 (31.75)
.404 (10.26) ± .062 (1.57)
CFR15AKE104--
.1
J, K, M
400
50
400
1.250 (31.75)
.441 (11.20) ± .062 (1.57)
CFR15AKE124--
.12
J, K, M
400
50
400
1.250 (31.75)
.491 (12.47) ± .062 (1.57)
CFR15AKE154--
.15
J, K, M
400
50
400
1.250 (31.75)
.456 (11.58) ± .062 (1.57)
CFR15AKE184--
.18
J, K, M
400
50
400
1.688 (42.88)
.500 (12.73) ± .062 (1.57)
CFR15AKE224--
.22
J, K, M
400
50
400
1.688 (42.88)
.533 (13.54) ± .093 (2.36)
CFR15AKE274--
.27
J, K, M
400
50
400
1.688 (42.88)
