INCH-POUND
MIL-PRF-49467/5D
13 February 2008
SUPERSEDING
MIL-PRF-49467/5C
22 April 2005
PERFORMANCE SPECIFICATION SHEET
CAPACITOR, CERAMIC, MULTILAYER,
HIGH VOLTAGE, 5,000 V DC, STYLE HV05
This specification sheet is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-49467.
Inches
mm
Inches
mm
Sizes (max.)
Lead spacing
Case
14.61
.575
0.05
.002
± .030
Width
Height
Thickness
code
15.24
.600
0.64
.025
(W)
(H)
(T)
(S)
17.02
.670
0.76
.030
E
.570
.500
.270
.475
17.15
.675
1.52
.060
F
.670
.600
.270
.575
18.29
.720
6.35
.250
G
.770
.720
.270
.675
19.56
.770
6.86
.270
J
1.250
.600
.270
1.100
27.94
1.100
7.11
.280
K
1.450
.720
.270
1.300
31.75
1.250
10.16
.400
M
.550
.280
.250
.400
33.02
1.300
12.07
.475
36.83
1.450
12.70
.500
38.10
1.500
13.97
.550
NOTES:
14.48
.570
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. H dimension includes meniscus.
4. S dimension shall be maintained from chip body to end of leads.
FIGURE 1. Capacitor style HV05.
AMSC N/A
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
