MIL-PRF-49467/4C
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Conformally coated, molded, or encapsulated.
Lead material: In accordance with MIL-PRF-49467.
Capacitance value: See table I.
Capacitance tolerance: J = ±5 percent, K = ±10 percent, M = ±20 percent. See table I.
Operating temperature range: -55°C to +125°C.
Voltage rating: 4,000 V dc.
Dielectric types: BP, BR, and BZ in accordance with MIL-PRF-49467.
Temperature coefficient: 0 ± 30 ppm/°C (BP), ±15 percent (BR, BZ).
Voltage-temperature limits: In accordance with MIL-PRF-49467.
Capacitance change with reference to +25°C
Symbol
Steps E through G of voltage-
Steps A through D of voltage-
temperature limit cycle table of
temperature limit cycle table of
MIL-PRF-49467.
MIL-PRF-49467. Bias = 0 volt.
100 percent rated voltage: 0 ± 30 ppm/°C
0 ± 30 ppm/°C
BP
BR
100 percent rated voltage: +15, -40 percent
±15 percent
BZ
60 percent rated voltage: +15, -45 percent
±15 percent
Dissipation factor (+25°C): 2.5 percent maximum (BR and BZ characteristic) or 0.1 percent maximum (BP
characteristic), measured under the same conditions as capacitance.
Resistance to soldering heat: In accordance with MIL-PRF-49467.
Partial discharge (corona): In accordance with MIL-PRF-49467.
Radiographic inspection (molded and encapsulated case types only): In accordance with MIL-PRF-49467.
Part or Identifying Number (PIN). See table I.
Marking: In accordance with MIL-PRF-49467.
2
