INCH-POUND
MIL-PRF-49467/1C
22 April 2005
SUPERSEDING
MIL-PRF-49467/1B
12 June 2001
PERFORMANCE SPECIFICATION SHEET
CAPACITOR, CERAMIC, MULTILAYER,
HIGH VOLTAGE, 1,000 V DC, STYLE HV01
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-49467.
Inches
mm
Inches
mm
Case
Sizes (max.)
Lead spacing
9.53
.375
0.05
.002
± .030
code
Width
Height
Thickness
10.16
.400
0.64
.025
(W)
(H)
(T)
(S)
11.94
.470
0.76
.030
.250
.220
.200
.170
A
12.07
.475
1.52
.060
.320
.280
.250
.220
B
12.70
.500
4.32
.170
.370
.300
.250
.275
C
14.48
.570
5.08
.200
.470
.400
.270
.375
D
14.61
.575
5.59
.220
.570
.500
.270
.475
E
15.24
.600
6.35
.250
.670
.600
.270
.575
F
17.02
.670
6.86
.270
G
.770
.720
.270
.675
17.15
.675
6.99
.275
18.29
.720
7.11
.280
NOTES:
19.56
.770
7.62
.300
1. Dimensions are in inches.
31.75
1.250
8.13
.320
2. Metric equivalents are given for general information only.
9.40
.370
3. H dimension includes meniscus.
4. S dimension shall be maintained from chip body to end of leads.
FIGURE 1. Capacitor style HV01.
AMSC N/A
1 of 5
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
