MIL-PRF-39018/4E
Dimensions
Dimensions
L ±.062 (1.57)
D ±.031 (0.79)
L ±.062 (1.57)
D ±.031 (0.79)
Case
Case
size
size
Nominal
Nominal
Nominal
Nominal
A0
2.125 (53.98)
1.375 (34.92)
F1
2.000 (50.80)
5.625 (142.88)
B0
3.125 (79.38)
1.375 (34.92)
B2
2.500 (63.50)
3.125 (79.38)
C0
4.125 (104.78)
1.375 (34.92)
C2
2.500 (63.50)
4.125 (104.78)
D0
4.625 (117.48)
1.375 (34.92)
D2
2.500 (63.50)
4.625 (117.48)
E0
5.125 (130.18)
1.375 (34.92)
E2
2.500 (63.50)
5.125 (130.18)
F0
5.625 (142.88)
1.375 (34.92)
F2
2.500 (63.50)
5.625 (142.88)
A1
2.125 (53.98)
2.000 (50.80)
C3
3.000 (76.20)
4.125 (104.78)
B1
3.125 (79.38)
2.000 (50.80)
D3
3.000 (76.20)
4.625 (117.48)
C1
4.125 (104.78)
2.000 (50.80)
E3
3.000 (76.20)
5.125 (130.18)
D1
4.625 (117.48)
2.000 (50.80)
F3
3.000 (76.20)
5.625 (142.88)
E1
5.125 (130.18)
2.000 (50.80)
FIGURE 1. Styles CU71 and CUR71 insulated capacitors - Continued.
