MIL-PRF-39003/9G
Dimensions
L ± .031 (0.79)
Case
D + .016 (0.41)
J max
size
- .015 (0.38)
C
.686 (17.42)
.289 (7.34)
.822 (20.88)
D
.786 (19.96)
.351 (8.92)
.922 (23.42)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are in parentheses and are given for general information only.
3. The case insulation shall extend .015 (0.38 mm) minimum beyond each end. However, when a shrink-fitted
insulation is used, it shall lap over the ends of the capacitor body.
4. Lead length may be a minimum of 1-inch long for use in tape and reel automatic insertion equipment, when
specified.
FIGURE 1. Dimensions and configuration Continued.
REQUIREMENTS:
Requirements: Requirements shall be in accordance with MIL-PRF-39003, and as specified herein.
Design and construction: Capacitors shall be of the design, construction, and physical dimensions specified on
figure 1.
Case type: Tubular, insulated.
Material: Metal (alloy unspecified).
Type of seal: Hermetic.
Leads: Type N of MIL-STD-1276, tin-lead plating, electrodeposited or hot-solder dipped.
DC related voltage: See table I. Above +85°C voltage derating is required (see MIL-PRF-39003).
DC leakage (DCL): See table I.
Capacitance (Cap.) (nom): See table I.
Cap. tolerance: 5, 10, and 20 percent, see table I.
Dissipation factor (DF): See table I.
Equivalent series resistance (ESR at 100 kHz): See table I.
Operating temperature: -55°C to +125°C.
Failure rate level: See table I.
2
