MIL-PRF-39003/3J
Dimensions
Case
L ± .031 (0.79)
D ± .016 (0.41)
M ± .002 (0.05)
size
J max
A
.286 ( 7.26)
.135 (3.43)
.020 (0.51)
.422 (10.72)
B
.474 (12.04)
.185 (4.70)
.020 (0.51)
.610 (15.49)
C
.686 (17.42)
.289 (7.34)
.025 (0.64)
.822 (20.88)
D
.786 (19.96)
.351 (8.92)
.025 (0.64)
.922 (23.42)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are in parentheses and are given for general information only.
3. The case insulation shall extend .015 (0.38 mm) minimum beyond each end. However, when a
shrink-fitted insulation is used, it shall lap over the ends of the capacitor body.
4. Lead length may be a minimum of 1-inch long for use in tape and reel automatic insertion equipment,
when specified.
FIGURE 1. Dimensions and configuration - Continued.
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1.
Case type: Tubular, insulated.
Material: Metal (alloy unspecified).
Type of seal: Hermetic.
Leads: Types N-32, N-52, W-32, or W-52 of MIL-STD-1276.
DC rated voltage: See table I. Above +85°C voltage derating is required (see MIL-PRF-39003).
DC leakage (DCL): See table I.
Capacitance (Cap.) (nom): See table I.
Cap. tolerance: See table I.
Dissipation factor (DF): See table I.
Operating temperature: -55°C to +125°C.
Failure rate level: See table I.
