MIL-PRF-23269/2H
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1.
Case material: Glass.
Terminals: Solderable.
Capacitance (nominal): See table I.
Capacitance tolerance: See table I.
Rated voltage: See table I.
Failure rate level: M, P, R, or S.
Rated temperature: -55°C to +125°C.
Temperature coefficient: 140 parts per million (ppm)/°C ±25 ppm/°C.
Capacitance drift: 0.1 percent or 0.1 pF, whichever is greater.
Seal: Hermetic.
Seal: Test I of MIL-PRF-23269.
Insulation resistance: 10,000 megohms or 200-ohm-farads minimum (qualification inspection only at +125°C).
100,000 megohms minimum (at 25°C).
Dissipation factor (DF): 0.1 percent maximum.
Thermal shock and moisture resistance:
DF: 0.1 percent maximum.
Quality factor (Q): In accordance with MIL-PRF-23269.
Life:
ĆCapacitance (240 hours and 2,000 hours): 0.5 percent maximum.
DF (240 hours and 2,000 hours): 0.15 percent maximum.
Marking:
"M" Part or Identifying Number (PIN)
"J" Brand in lieu of slash
M23269J
02-3001
TM 09A
|
Trademark
Year
Sequential 4 week lot code
code
Substitutability data: See table II.
2
