MIL-PRF-14409/7E
REQUIREMENTS:
Dimensions: See figure 1 and table I.
DC voltage rating: 750 volts.
Construction: Glass or quartz, see figure 1 and table I.
Insulation resistance (IR): Method 302 of MIL-STD-202, test condition B (500 volts ±10 percent); not less than
1,000,000 megohms, except characteristics J and H shall be not less than 100,000 megohms at 125°C.
Capacitance range: See table I.
Quality factor (Q): See table I.
Thermal shock: Method 107 of MIL-STD-202, test condition A, except the step 3 temperature shall be 125°C
±5°C for characteristics J and H, and 150°C ±5°C for characteristic Q.
TABLE I. Type designation and characteristics.
Capacitance
Dimensions 1/
Type
Dielectric
Wire size
range
Q
designation
material
AWG
B ±.031 (0.79)
Min
Max
A (max)
T (max)
pF
pF
0.6
1.8
PC41Q1R8
.250 ( 6.35)
.312 ( 7.92)
.181 (4.60)
1,500
Quartz
24
0.6
5.5
PC41Q5R5
.438 (11.13)
.562 (14.27)
.186 (4.72)
1,500
Quartz
22
0.6
9.5
PC41Q9R5
.875 (22.23)
1.000 (25.40)
.211 (5.36)
1,500
Quartz
22
0.8
16.0
PC41Q160
1.375 (34.93)
1.609 (40.87)
.196 (4.98)
1,500
Quartz
22
0.8
5.5
PC51J5R5
.250 ( 6.35)
.312 ( 7.92)
.181 (4.60)
1,000
Glass
24
0.8
11.0
PC51J110
.438 (11.13)
.562 (14.27)
.186 (4.72)
900
Glass
22
0.8
16.0
PC51H160
.625 (15.88)
.766 (19.46)
.231 (5.87)
800
Glass
22
0.8
23.0
PC51H230
.875 (22.23)
1.000 (25.40)
.211 (5.36)
700
Glass
22
PC51H380
0.8
38.0
1.375 (34.93)
1.609 (40.87)
.196 (4.98)
500
Glass
22
1/ Metric equivalents (to the nearest 0.01 mm) are given for general information only. Millimeters are in parentheses.
TABLE II. Substitutability data.
Superseded type
Substitutable type
designation in
designation in
MIL-C-14409/7
MIL-PRF-14409/7A through /7E
PC41J4R5 and PC47J050
PC51J5R5
PC41J8R5 and PC47J100
PC51J110
PC41H120 and PC47H140
PC51H160
PC41H180 and PC47H190
PC51H230
PC41H300
PC51H380
