MIL-PRF-14409/17C
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
DC voltage rating: 250 volts.
Construction: Glass, O-ring sealed.
Dielectric: Glass.
Capacitance range: See table I.
Insulation resistance: Shall be not less than 1,000,000 megohms at room ambient temperature and not less than
100,000 megohms at +125°C.
Test condition: 250 volts ±10 percent.
Quality factor (Q): See table I.
Driving torque: Greater than or equal to 0.5 ounce-inches and less than or equal to 5.0 ounce-inches from -55°C to
+125°C.
Thermal shock: Method 107 of MIL-STD-202, test condition A, except step 3 temperature shall be +125° ±5°C.
Immersion: Method 104 of MIL-STD-202, test condition A.
Resistance to soldering heat: In accordance with MIL-PRF-14409.
Seal: In accordance with MIL-PRF-14409.
TABLE I. Capacitor characteristics.
Capacitance
Dimensions 1/
Part or
Q
A ± .030
range
Indentifying
minimum
Number (PIN)
Min
Max
(0.76)
pF
pF
PC17J5R5
1.0
5.5
1000
.390
(9.91)
PC17J8R5
1.0
8.5
650
.535
(13.59)
PC17G100
1.5
10
800
.340
(8.64)
PC17G200
1.5
20
800
.410
(10.41)
PC17G300
1.5
30
800
.490
(12.45)
PC17G400
1.5
40
800
.600
(15.24)
1/ Metric equivalents are shown in parentheses for information only.
Qualification inspection: Qualification inspection is not required. A manufacturer that is currently listed on the QPL
for at least one other MIL-PRF-14409 style may supply PC17 parts by performing the group A and group B testing.
A manufacturer that is not qualified to any MIL-PRF-14409 styles may produce these parts by performing the group
A, group B, and group C testing on the product before delivery.
