MIL-PRF-123/8D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Tubular, molded, or preformed plastic encapsulated.
Lead wire: Termination W in accordance with MIL-PRF-123.
Capacitance value: See table I.
Capacitance tolerance: See table I (F = ±1 percent; J = ±5 percent; K = ±10 percent).
Operating temperature: -55°C to +125°C.
Voltage rating: See table I (B = 50 Vdc; C = 100 Vdc; D = 200 Vdc).
Marking: In accordance with MIL-PRF-123, example 5.
TABLE I. Style CKS16 characteristics.
Part or Identifying
Capacitance
Capacitance
Voltage-temperature
Rated voltage
Number (PIN) 1/
(pF)
tolerance
limits
(volts, dc)
M123A08BPC242-W
2,400
F, J, K
BP
100
M123A08BPC272-W
2,700
F, J, K
BP
100
M123A08BPC302-W
3,000
F, J, K
BP
100
M123A08BPC332-W
3,300
F, J, K
BP
100
M123A08BPC362-W
3,600
F, J, K
BP
100
M123A08BP-392-W
3,900
F, J, K
BP
100, 200
BP
M123A08BP-432-W
4,300
F, J, K
100, 200
BP
M123A08BP-472-W
4,700
F, J, K
100, 200
BP
M123A08BP-512-W
5,100
F, J, K
100, 200
BP
M123A08BP-562-W
5,600
F, J, K
100, 200
BP
M123A08BP-622-W
6,200
F, J, K
100, 200
BP
M123A08BP-682-W
6,800
F, J, K
100, 200
BP
M123A08BP-822-W
8,200
F, J, K
100, 200
BP
M123A08BP-912-W
9,100
F, J, K
100, 200
M123A08BP-103-W
10,000
F, J, K
BP
100, 200
M123A08BPB113-W
11,000
F, J, K
BP
50
M123A08BPB123-W
12,000
F, J, K
BP
50
M123A08BPB133-W
13,000
F, J, K
BP
50
M123A08BP-153-W
15,000
F, J, K
BP
50, 100
M123A08BP-163-W
16,000
F, J, K
BP
50, 100
M123A08BP-183-W
18,000
F, J, K
BP
50, 100
M123A08BP-203-W
20,000
F, J, K
BP
50, 100
M123A08BP-223-W
22,000
F, J, K
BP
50, 100
M123A08BPC273-W
27,000
F, J, K
BP
100
M123A08BPC333-W
33,000
F, J, K
BP
100
M123A08BPC393-W
39,000
F, J, K
BP
100
M123A08BPB473-W
47,000
F, J, K
BP
50
M123A08BPB563-W
56,000
F, J, K
BP
50
M123A08BPB683-W
68,000
F, J, K
BP
50
M123A08BPB823-W
82,000
F, J, K
BP
50
See footnote at end of table.
2
