MIL-PRF-123/7E
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Tubular, molded, or preformed plastic encapsulated.
Lead wire: Termination W in accordance with MIL-PRF-123.
Capacitance value: See table I.
Capacitance tolerance: See table I (F = ±1 percent; J = ±5 percent; K = ±10 percent).
Operating temperature: -55°C to +125°C.
Voltage rating: See table I (B = 50 Vdc; C = 100 Vdc; D = 200 Vdc).
Marking: In accordance with MIL-PRF-123, example 5.
TABLE I. Style CKS15 characteristics.
Part or Identifying
Capacitance
Capacitance
Voltage-temperature
Rated voltage
Number (PIN) 1/
(pF)
tolerance
limits
(volts, dc)
M123A07BPD821-W
820
F, J, K
BP
200
M123A07BPD102-W
1,000
F, J, K
BP
200
M123A07BP-112-W
1,100
F, J, K
BP
100, 200
M123A07BP-122-W
1,200
F, J, K
BP
100, 200
M123A07BP-132-W
1,300
F, J, K
BP
100, 200
M123A07BP-152-W
1,500
F, J, K
BP
100, 200
BP
M123A07BP-162-W
1,600
F, J, K
100, 200
BP
M123A07BP-182-W
1,800
F, J, K
100, 200
BP
M123A07BP-202-W
2,000
F, J, K
100, 200
M123A07BP-222-W
2,200
F, J, K
BP
100, 200
M123A07BP-242-W
2,400
F, J, K
BP
50, 200
M123A07BP-272-W
2,700
F, J, K
BP
50, 200
M123A07BP-302-W
3,000
F, J, K
BP
50, 200
M123A07BP-332-W
3,300
F, J, K
BP
50, 200
M123A07BPB362-W
3,600
F, J, K
50
BP
M123A07BP-392-W
3,900
F, J, K
50, 100
BP
M123A07BP-432-W
4,300
F, J, K
50, 100
BP
M123A07BP-472-W
4,700
F, J, K
50, 100
BP
M123A07BP-512-W
5,100
F, J, K
50, 100
BP
M123A07BP-562-W
5,600
F, J, K
50, 100
BP
M123A07BP-622-W
6,200
F, J, K
50, 100
BP
M123A07BP-682-W
6,800
F, J, K
50, 100
BP
M123A07BP-752-W
7,500
F, J, K
50, 100
BP
M123A07BP-822-W
8,200
F, J, K
50, 100
BP
M123A07BP-912-W
9,100
F, J, K
50, 100
BP
M123A07BP-103-W
10,000
F, J, K
50, 100
BP
M123A07BP-113-W
11,000
F, J, K
50, 100
BP
M123A07BP-123-W
12,000
F, J, K
50, 100
BP
M123A07BPB133-W
13,000
F, J, K
50
BP
M123A07BPB153-W
15,000
F, J, K
50
BP
M123A07BPB163-W
16,000
F, J, K
50
BP
M123A07BPB183-W
18,000
F, J, K
BP
50
See footnote at end of table.
2
