MIL-PRF-123/5D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Tubular, molded or preformed plastic encapsulated.
Lead wire: Termination W in accordance with MIL-PRF-123.
Capacitance value: See table I.
Capacitance tolerance: See table I (F = ±1 percent; J = ±5 percent; K = ±10 percent).
Operating temperature: -55°C to +125°C.
Voltage rating: See table I (B = 50 Vdc; C = 100 Vdc; D = 200 Vdc).
Marking: In accordance with MIL-PRF-123, example 4.
TABLE I. Style CKS12 characteristics.
Part or Identifying
Capacitance
Capacitance
Voltage-temperature
Rated voltage
Number (PIN) 1/
(pF)
tolerance
limits
(volts, dc)
M123A05BPD820-W
82
F, J, K
BP
200
M123A05BPD910-W
91
F, J, K
BP
200
M123A05BPD101-W
100
F, J, K
BP
200
M123A05BP-111-W
110
F, J, K
BP
100, 200
M123A05BP-121-W
120
F, J, K
BP
100, 200
M123A05BP-131-W
130
F, J, K
BP
100, 200
M123A05BPC151-W
150
F, J, K
BP
100
M123A05BPC161-W
160
F, J, K
BP
100
M123A05BPC181-W
180
F, J, K
BP
100
M123A05BPC201-W
200
F, J, K
BP
100
M123A05BPC221-W
220
F, J, K
BP
100
M123A05BPB241-W
240
F, J, K
BP
50
M123A05BP-271-W
270
F, J, K
BP
50, 100
M123A05BP-301-W
300
F, J, K
BP
50, 100
M123A05BP-331-W
330
F, J, K
BP
50, 100
M123A05BP-361-W
360
F, J, K
BP
50, 100
M123A05BP-391-W
390
F, J, K
BP
50, 100
M123A05BP-431-W
430
F, J, K
BP
50, 100
M123A05BP-471-W
470
F, J, K
BP
50, 100
M123A05BPC511-W
510
F, J, K
BP
100
M123A05BPC561-W
560
F, J, K
BP
100
M123A05BPC621-W
620
F, J, K
BP
100
M123A05BPC681-W
680
F, J, K
BP
100
M123A05BPB751-W
750
F, J, K
BP
50
M123A05BPB821-W
820
F, J, K
BP
50
M123A05BPB911-W
910
F, J, K
BP
50
M123A05BPB102-W
1,000
F, J, K
BP
50
See footnote at end of table.
