MIL-PRF-123/18C
Inches
mm
Inches
mm
Inches
mm
.004
0.10
.019
0.48
.092
2.34
.006
0.15
.020
0.51
.148
3.76
.007
0.18
.028
0.71
.260
6.60
.010
0.25
.035
0.89
.283
7.19
.012
0.30
.058
1.47
.320
8.13
.015
0.38
.090
2.29
.325
8.26
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information.
3. Leads shall be centered within ± .005 (0.13 mm).
4. The angle shall be 95° +10°, -5°.
5. The distance between the centers of the mounting holes will be .300 ± .010 inch (7.62 ± 0.25 mm).
6. Nonconductive material shall not extend beyond .030 inch (0.76 mm) from the edge of the capacitor body.
FIGURE 1. Style CKS24 capacitors - Continued.
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Molded plastic, encapsulated.
Lead wire: Type C of MIL-PRF-123.
Capacitance value: See table I.
Capacitance tolerance: See table I.
Operating temperature: -55°C to +125°C.
Voltage-temperature limits: BR and BX characteristics.
Voltage rating: See table I.
Pre-encapsulation terminal strength: In accordance with MIL-PRF-123.
Marking: In accordance with MIL-PRF-123, example 6.
