MIL-PRF-123-16 Capacitors, Fixed, Ceramic Dielectric, \(Temperature Stable And General Purpose\), High Reliability, Leaded, Style Cks22

Pages 1 - 2 - 3 - 4

MIL-PRF-123/16C

Inches

.004

0.10

.019

0.48

.092

2.34

.006

0.15

.020

0.51

.128

3.25

.007

0.18

.028

0.71

.148

3.76

.010

0.25

.035

0.89

.175

4.44

.012

0.30

.058

1.47

.260

6.60

.015

0.38

.090

2.29

.325

8.26

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for general information only.

3. Leads shall be centered within � .005 (0.13 mm).

4. The angle shall be 95� +10�, -5�.

5. The distance between the centers of the mounting holes will be .300 � .010 inch (7.62 � 0.25 mm).

6. Nonconductive material shall not extend beyond .030 inch (0.76 mm) from the edge of the capacitor body.

FIGURE 1. Style CKS22 capacitors - Continued.

REQUIREMENTS:

Dimensions and configuration: See figure 1.

Case type: Molded plastic, encapsulated.

Lead wire: Type C of MIL-PRF-123.

Capacitance value: See table I.

Capacitance tolerance: See table I (D = �0.5 pF, F = �1 percent; J = �5 percent; K = �10 percent, M = �20

percent).

Operating temperature: -55�C to +125�C.

Voltage rating: See table I (B = 50 Vdc; C = 100 Vdc; D = 200 Vdc).

Temperature coefficient tolerances for BP values below 20 pF: In accordance with MIL-PRF-123.

Pre-encapsulation terminal strength: In accordance with MIL-PRF-123.

Marking: In accordance with MIL-PRF-123, example 6.
