MIL-PRF-123/11E
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case type: Multilayer, unencapsulated, monolithic ceramic.
*
Termination: M, G, S, or Z in accordance with MIL-PRF-123.
Capacitance value: See table I.
*
Capacitance tolerance: See table I. (F = ±1 percent; J = ±5 percent; K = ±10 percent; M = ±20 percent.)
Operating temperature: -55°C to +125°C.
*
Rated voltage: See table I. 50 Vdc (voltage code B) and 100 Vdc (voltage code C).
Marking: In accordance with MIL-PRF-123.
*
TABLE I. Style CKS52 characteristics.
Part or Identifying
Capacitance
Capacitance
Voltage-temperature
Rated voltage
Number (PIN) 1/
(pF)
tolerance
limits
(volts, dc)
50, 100
BP
F, J, K
300
M123A11BP-301--
50, 100
BP
F, J, K
330
M123A11BP-331--
50, 100
BP
F, J, K
360
M123A11BP-361--
50, 100
BP
F, J, K
390
M123A11BP-391--
50, 100
BP
F, J, K
430
M123A11BP-431--
50, 100
BP
F, J, K
470
M123A11BP-471--
50, 100
BP
F, J, K
510
M123A11BP-511--
50, 100
BP
F, J, K
560
M123A11BP-561--
50, 100
BP
F, J, K
620
M123A11BP-621--
50, 100
BP
F, J, K
680
M123A11BP-681--
50, 100
BP
F, J, K
750
M123A11BP-751--
50, 100
BP
F, J, K
820
M123A11BP-821--
50, 100
BP
F, J, K
910
M123A11BP-911--
50, 100
BP
F, J, K
1,000
M123A11BP-102--
50, 100
BP
F, J, K
1,100
M123A11BP-112--
50, 100
BP
F, J, K
1,200
M123A11BP-122--
50, 100
BP
F, J, K
1,300
M123A11BP-132--
50, 100
BP
F, J, K
1,500
M123A11BP-152--
50, 100
BP
F, J, K
1,600
M123A11BP-162--
50, 100
BP
F, J, K
1,800
M123A11BP-182--
50, 100
BP
F, J, K
2,000
M123A11BP-202--
50, 100
BP
F, J, K
2,200
M123A11BP-222--
50
BP
F, J, K
2,400
M123A11BPB242--
50
BP
F, J, K
2,700
M123A11BPB272--
50
BP
F, J, K
3,000
M123A11BPB302--
50
BP
F, J, K
3,300
M123A11BPB332--
50, 100
BX
K, M
5,600
M123A11BX-562--
50, 100
BX
K, M
6,800
M123A11BX-682--
50, 100
BX
K, M
8,200
M123A11BX-822--
50, 100
BX
K, M
10,000
M123A11BX-103--
50, 100
BX
K, M
12,000
M123A11BX-123--
50, 100
BX
K, M
15,000
M123A11BX-153--
50, 100
BX
K, M
18,000
M123A11BX-183--
50, 100
BX
K, M
22,000
M123A11BX-223--
1/ See footnote at end of table.
