MIL-C-5/1H
REQUIREMENTS:
Dimensions: See figure 1.
Capacitance value: See table I.
Capacitance tolerance: See table I.
Symbol
Capacitance tolerance
± 0.5 pF
D
± 1 percent
F
± 2 percent
G
± 5 percent
J
DC rated voltage: See table I.
Operating temperature range: See table I.
Symbol
Temperature range
-55°C to +85°C
N
-55°C to +125°C
O
-55°C to +150°C
P
Vibration grade: 3 (10 to 2,000 Hz).
Characteristic: See table I.
Temperature coefficient P/M/°C
Capacitance drift
Symbol
± (0.5 percent +0.1 PF)
C
-200 to + 200
± (0.1 percent +0.1 PF)
E
-20 to + 100
± (0.05 percent +0.1 PF)
F
0 to + 70
Barometric pressure (qualification only): As specified in MIL-C-5 with condition D (100,000 ft) and 150 percent of
rated dc voltage.
Immersion: As specified in MIL-C-5 except, capacitance change shall not exceed ±2 percent of nominal value or 1 pf,
whichever is greater.
Moisture resistance: As specified in MIL-C-5 except, capacitance change shall not exceed ±2 percent of nominal
value or 1 pf, whichever is greater.
Qualification inspection: Qualification inspection is required. A manufacturer that is currently listed on the QPL for at
least one other MIL-C-5 style may become qualified to the CM15 style by contacting the qualifying activity listed in the
basic specification.
2
