MIL-C-11272/2F
REQUIREMENTS:
Requirements: Requirements shall be in accordance with MIL-C-11272, and as specified herein.
*
Dimensions and configuration: See figure 1.
Capacitance: See table I.
Capacitance tolerance: F = ±1%; G = ±2%; J = ±5%.
Table I. CY15 Electrical Characteristics
Capacitance
DC
tolerances
Pin 1/
Capacitance
rated
available
voltage
pF
volts
CY15C221-
220
500
FGJ
CY15C241-
240
500
FGJ
CY15C271-
270
500
FGJ
CY15C301-
300
500
FGJ
CY15C331-
330
500
FGJ
CY15C361-
360
500
FGJ
CY15C391-
390
500
FGJ
CY15C431-
430
500
FGJ
CY15C471-
470
500
FGJ
CY15C511-
510
500
FGJ
CY15C561-
560
300
FGJ
CY15C621-
620
300
FGJ
CY15C681-
680
300
FGJ
CY15C751-
750
300
FGJ
CY15C821-
820
300
FGJ
CY15C911-
910
300
FGJ
CY15C102-
1,000
300
FGJ
CY15C112-
1,100
300
FGJ
CY15C122-
1,200
300
FGJ
1/ Complete type designation will include an additional letter
*
symbol to indicate capacitance tolerance.
