INCH-POUND
MIL-C-11272/17B
7 February 2003
SUPERSEDING
MIL-C-11272/17A(USAF)
6 July 1973
MILITARY SPECIFICATION
CAPACITORS, FIXED, PORCELAIN DIELECTRIC,
STYLES CY83 AND CY84
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
INACTIVE FOR DESIGN AFTER
16 JULY 1979. USE MIL-PRF-55681/4.
Inches
mm
.010
.25
.015
.38
.020
.51
.060
1.52
.100
2.54
Dimensions
.110
2.79
T
Style
L
W
Min.
Max.
.110 ±.015
.110 ±.015
CY83
.060
.100
.110 ±.020
.110 ±.015
CY84
.060
.100
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 1. Capacitors, fixed, porcelain dielectric,
styles CY83 and CY84.
AMSC N/A
1 of 5
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
