MIL-C-11272/14C
REQUIREMENTS
Requirements: Requirements shall be in accordance with MIL-C-11272, and as specified herein.
*
Dimensions and configuration: See figure 1.
Dielectric: Glass
Case: Epoxy.
*
Terminals: Solderable
Capacitance value: See table I.
Capacitance tolerance: F = ±1%; G = ±2%; J = ±5%.
DC rated voltage: 300 volts.
*
Quality factor (Q): In accordance with MIL-C-11272 and the following:
Not less than 1,000.
TABLE I. Style CY07.
Capacitance
tolerances
DC rated
PIN 1/
Capacitance
available
voltage
(pF)
CY07C621-
620
300
FGJ
CY07C681-
680
300
FGJ
CY07C751-
750
300
FGJ
CY07C821-
820
300
FGJ
CY07C911-
910
300
FGJ
CY07C102-
1000
300
FGJ
*
1/ Complete PIN will include an additional letter symbol to indicate capacitance
tolerance.
*
Life: In accordance with MIL-C-11272 and the following:
For qualification test:
At 25°C:
Insulation resistance: Not less than 100,000 megohms.
Capacitance: Change not more than 0.5 percent of nominal value from initial 25°C value.
Dissipation factor: Not to exceed 0.0025.
At 125°C:
Insulation resistance: Not less than 10,000 megohms.
Capacitance: Change not more than 0.5 percent of nominal value from initial 125°C value.
Dissipation factor: Not to exceed 0.007.
