MIL-C-11015/9F
TABLE I. Style CK60 characteristics.
Capacitance
Capacitance
PIN
1/
Rated
Rated temperature
tolerance
voltage
and voltage-
temperature limits
Volts, dc
pF
CK60BX2R2K-
1,000
BX
2.2
K
CK60BX3R3K-
1,000
BX
3.3
K
CK60BX4R7K-
1,000
BX
4.7
K
CK60BX6R8K-
1,000
BX
6.8
K
CK60BX100K-
1,000
BX
10
K
CK60BX150K-
1,000
BX
15
K
CK60BX220K-
1,000
BX
22
K
CK60BX330--
1,000
BX
33
K, M
CK60BX470--
1,000
BX
47
K, M
CK60BX680--
1,000
BX
68
K, M
CK60BX101--
1,000
BX
100
K, M
CK60BX151--
500
BX
150
K, M
CK60AX221--
1,000
AX
220
K, M
CK60AX331--
500
AX
330
K, M
CK60AX471--
500
AX
470
K, M
CK60AW471M-
1,000
AW
470
M
CK60AW681M-
1,000
AW
680
M
CK60AW102M-
1,000
AW
1,000
M
CK60AW152M-
500
AW
1,500
M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance. The
PIN will also include the letter "E" to indicate an epoxy coated capacitor (when applicable) or "-" will be deleted for
wax impregnated case.
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Disk, wax impregnated or epoxy coated (E).
Capacitance value - See table I.
Capacitance tolerance -
10 percent (K) or 20 percent (M) as shown in table I.
Rated temperature - -55 C to +85 C (A) or -55 to +125 C (B) as shown in table I.
Dielectric withstanding voltage (DWV): In accordance with MIL-C-11015.
Dielectric:
Test voltage - 250 percent of rated voltage.
Body insulation:
Test potential - 1,300 volts dc.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202, 0.82 inch of
mercury (80,000 ft).
Test potential - 150 percent of rated voltage or 1,300 volts dc, whichever is less.
